Electronics Assembly Zone
Purpose: This zone is dedicated to the precise assembly and integration of printed circuit boards (PCBs) and electronic modules, essential for drone and IoT system functionality. It houses high-end machinery for surface mount technology (SMT), inspection, and reflow soldering processes to ensure production-grade reliability.
Machines Used: A combination of automatic and semi-automatic machines are deployed to handle both prototyping and batch manufacturing efficiently.
Machinery & Equipment:
- Solder Paste Printer
- 3D Solder Paste Inspection Machine (SPI)
- Pick and Place Machine with Vision System
- 8-Head Automatic Component Picking System
- Reflow Oven (Convection Type)
- Soldering Workstation (ESD Safe)
- Hot Air Rework Station
- Multimeter, Oscilloscope & Logic Analyzer
- Materials Used: PCB, ESCs, Flight Controllers, Resistors, Capacitors, ICs, Connectors, Wires
Key Highlights:
- SMT and THT compatible workflow
- High precision placement for SMD components
- Low to medium batch production support
- Designed for prototyping and educational training
Process Flow:
- Apply solder paste to PCB pads
- Pick and place SMD components
- Pass through reflow oven
- Automated Inspection (SPI)
- Manual soldering & rework (if needed)
- Final testing and validation
Safety Measures:
- ESD wrist straps for all operators
- Fume extractors at soldering stations
- Fire extinguishers and emergency cut-off switches
- Protective eyewear and gloves provided
